| Capacity (Gallons) |
Model No. |
Dimensions |
# of Shelves |
# of Tray Liners |
# of Doors |
Weight |
| 6 |
FK06* |
23"W x 18"D x 22"H |
0 |
1 |
1 |
98 lbs. |
| 12 |
FK12 |
23"W x 18"D x 35"H |
1 |
2 |
1 |
144 lbs. |
| 18 |
FK18 |
23"W x 18"D x 44"H |
2 |
3 |
1 |
182 lbs. |
| 24 |
FK24 |
23"W x 18"D x 65"H |
3 |
4 |
1 |
254 lbs. |
- FM Approved!
- All welded double wall 18 gauge construction with 1-1/2" insulating air space.
- 2" leakproof sill to contain leaks.
- Lockable flush mounted handle with 2 keys.
- Doors have 3 point locking system and radius edges.
- Doors are double walled, 14 gauge outside & 18 gauge inside.
- 4" heavy duty welded hinges with brass pins.
- Twin 2" flame arrester vents.
- Adjustable leveling feet.
- Powder coated forest green finish.
- Safety signage in large red letters.
- Galvanized steel shelf louver at mid height.
- Polyethylene tray liner for shelves & sill
- Grounding connector.
- Meets OSHA, and NFPA code 30 & UFC 79 standards.
- Self close doors(shut, index (2 door models only), and latch automatically as fusible link melts under fire conditions at 165°).
- Concealed self closing mechanism.
- Chemical storage maximum - Class I & II - 60 gallons, Class III - 120 gallons
